USING THE WARM FRONT ROOM THERMOSTAT
Warm is shown by red lights (6) and Cool is shown by a
blue light (5). The centre button (3) marked 'Warm /
Cool' allows you to toggle between warm and cool
settings.
When one or more red lights are on, you can increase
the temperature by pressing the '+' button (1). For
example, press once to go up by 1 degree C, or press
twice to go up by 2 degrees C.
When the two or three red lights are on, the tem-
perature can also be lowered to the centre position by
using the '-' button (2). For example, press once to go
down to the central temperature and press again to go
down to one degree below central temperature.
The Blue light means the unit is working to the lower
temperature and the '+' or '-' buttons do not work when
this blue light is on.
Under the flap (7) is a Blue button (4). During the summer, or when you want your central heating off for long periods, for example
if you go on holiday, press the Blue button and close the flap. When you want to go back to normal operation, open the flap and
press the Blue button again, remembering to close the flap once finished.
User Operations
1
4
2
3
5
6
7
