Horwin EK3 - Key Vehicle Technical Specifications

37
Item
Parameters
Motor type
DC motor
Rated power
3.5KW
Maximum power
6.2KW
Maximum Speed
95km/h
Range (AT 45 KM/H WITH
100KM
Battery capacity
40AH
Battery type
Lithium battery
Instrument
LCD
Lamp system of the vehicle
LED
Brake system
CBS oil brake
Battery voltage
72V
Standard charging current
10A
Charging time
4H
Wheelbase
1320mm
Minimum ground clearance
125mm
Steering angle
44°
Front hub
MT2.5×14
Rear hub
MT3.0×13
Front tire size
100/80-14
Rear tire size
110/70-13
Front braking method
Oil brake
Rear braking method
Oil brake
Length of vehicle
1900mm
Width
690mm
Height
1130mm
Seat height
780mm
Net weight without battery
95KG
Technically permissible maximum laden mass
284KG
