9
Evaporator Spray Tube Water Valve
Expansion Valve Water Supply Inlet
Check Valve
Hot Gas Valve
Junction Box
Control Box
Water-cooled
Condenser
Line Valve
Water Regulator
Water Pump
Float Switch Transformer Box
Cleaning Valve
Drier
Compressor
Control Switch Bin Control Thermostat
II. GENERAL INFORMATION
1. CONSTRUCTION
[a] KM-2000SWF3, KM-2000SWH3
