Mounting Wheels to the Wheel Arms
Materials Required:
2 – 15” Steel Wheels
4 – Steel Dust Caps
1 – 3/8” Axle Shaft with Nylon Lock Nuts
1) Insert the Axle Shaft through the Wheel Mounting
Arms.
2) Place the Dust Caps onto the Wheel Hubs and
slide the Wheels onto the Axle Shaft.
3) Thread the Lock Nuts onto each end of the Axle
Shaft
4) Using the two 1/2” wrenches, hold the nut on the
left while tightening the nut on the right.
*Note: Tighten Lock Nuts until both nuts bottom out
on Axle Shaft.
Dust Cap
Dust Cap
Dust Cap
Dust Cap
½”wrenches
fitted onto
lock nuts
