Hotpoint 15 - Transferring Freezer Door Handle; Freezer Door Handle Transfer

REVERSING THE DOOR SWING (CONT.)
2
20
Installation Instructions
5.4 Transfer Freezer Door Handle
5.4.1 Remove the screw holding the handle to
the top of the door and the two screws
holding the handle to the bottom of the
door.
5.4.2 Remove the handle.
5.4.3 Remove the screw from the right top edge of the
door and insert it into the handle screw hole on
the left side.
5.4 Transfer Freezer Door Handle (cont.)
5.4.4 Transfer the door stop as shown on the
preceding page.
5.4.5 Attach the handle to the right edge of the door
with screws at top and bottom, using bottom
holes vacated by removal of the door stop
screws.
TOP
BOTTOM
Top
Bottom
