Shelves
Shelves in the fresh food and freezer
compartments are adjustable,
enabling you to make efficient shelf
arrangements to fit your family’s
food storage needs.
Adjwtible Shelves in
Fresh Food Compartment
To remove shelves:
Tilt shelf up at
front, then lift it up and out of
tracks on rear wall of refrigerator.
Engage
top
lug~
<--
~
Lower to
lock
Into
place
IF
I
?
,/’
*“
I
To replace shelves:
Select desired
shelf height. With shelf front raised
slightly, engage top lugs in tracks at
rear of cabinet. Then lower front of
shelf until it locks into position.
Removable Bins on Fresh
Food Compartment Door
1,1
To remove:
Lift the bin straight up
until mounting hooks disengage.
To relocate: Select desired shelf
height, engage the bin’s hook
in
slots on the tracks of the door, and
push in. The bin will lock in place.
Removable Shelves in
Freezer Compartment
Shelves in the freezer compartment
are easily removed and replaced.
To remove shelves:
1.
While pressing tabs on shelf
supports on right wall, lift shelf out
of grooves in supports.
2. Pull shelf sideways until rods
come out of holes on left wall.
To replace shelves:
Insert rods into
holes. Then, while pressing tabs,
lower shelf into grooves in supports.
Be sure shelf wire is fully inserted
into grooves.
