Service Manual UK
Whirlpool UK Appliances Ltd
English
INTRODUCTION OF HOTPOINT COOKER HOOD - HSFX.1
This model was introduced into the Hotpoint built in range in October 2015. It has 3 speed, slider
controls with 2 x 28W lights. This model replaces HSFX.
SPECIFICATIONS
Model Commercial Code Colour
HSFX.1 88215 Stainless Steel
Country of Origin Italy
Position of Rating Plate Underneath grease filters
Dimensions
Height 173 mm
Width 598 mm
Depth 295 mm - 450 mm
Weight Unpacked - 6.0 kg Packed - 7.5 kg
Noise Maximum - 57 dB
Electrical Supply 230/240Volts AC @ 50Hz
Extraction Rate 185 (m3/h)
Total Power 156 Watts
Motor 100W
Energy Efficiency Class E
Lamps 2 x Halogen 28W - E14 - 35 mm
Air Outlet 150 mm
Carbon Filter Supplied
Grease Filter Supplied x 2
Mains Cable 1.5 m, HO5VV-F 2 x 0.75mm
2
Approvals
This appliance conforms to the following EEC Directives:
Low Voltage Equipment Directive 2006/95/EC (12-12-2006)
Electromagnetic Compatibility Directive 2004/108/EC (15-12-2004)
