Hotpoint MWH221 - Page 7

7
B
=
B
=
H
H
B H
X
Fix the fastening bar such that the two lips stick out over the edge of the bottom of the recess and rest against it
at the front.
2. Remove the 2 screws (X)from the fastening bar under the microwave oven.
3. Fit the fastening bar (B) at the correct position in the recess. Make sure that there is the same amount of free
space at each side of the fastening bar. Fasten the fastening bar using the two 16 mm. screws (H) which can
be found in the accessory bag.
