31-7000091 Rev. 2 11
INSTALLATION TYPES (Choose A, B or C)
This microwave oven is designed for adaptation to
the following three types of ventilation:
A. Recirculating (Non-Vented Ductless)
B. Outside Top Exhaust (Vertical Duct)
C. Outside Back Exhaust (Horizontal Duct)
NOTE: Select the type of ventilation required for your
installation and proceed to that section.
B
OUTSIDE TOP EXHAUST
(VERTICAL DUCT)
See page 16
Adaptor in Place
for Outside Top
Exhaust
Installation Instructions
2
OUTSIDE BACK EXHAUST
(HORIZONTAL DUCT)
See page 20
C
RECIRCULATING
(NON-VENTED DUCTLESS)
See page 12
A Charcoal Filter Accessory Kit is required for the
non-vented exhaust. (See your Owner’s Manual for the
kit number.)
A
