1. INSTALLATION
1.1. INSTALLING SINGLE APPLIANCE
To guarantee adequate ventilation, leave a space on
both sides and above the appliance.
The distance between the rear of the appliance and the
wall behind the appliance should be at least 50mm.
A reduction of this space will increase the Energy
consumption of product.
1.2. INSTALLING TWO APPLIANCES
During installing the freezer
1
and the fridge
2
together ensure that the freezer is located on the left
and the fridge on the right (as shown on the drawing).
Left side of refrigerator is equipped with special device
in order to avoid condensation problems between
appliances.
We recommended installing two appliances together
using the linking-kit
3
(as shown on the drawing).
You can buy it in Service.
To level the doors using the adjustable lower hinge
(select models).
If the refrigerator door is lower than the freezer door,
raise the refrigerator door by turning the adjustment
screw counterclockwise using a M10 wrench.
If the freezer door is lower than the refrigerator door,
raise the freezer door by turning the adjustment screw
counterclockwise using a M10 wrench.
50mm
50mm
5 mm
max
