Essential Information
SUPPLY
220/240v v
D 50Hz
a
B Earth +
NAN
>
FUSES
CHANGING THE PLUG
Green and yellow
- (Earth) wire to the
terminal marked
| ‘E or with the
_ symbol -or
La
ISA
ASTA
y i approved
fuse to BS1362.
Blue (Neutral) Brown (Live)
wire to the
terminal marked
Cord ‘L’ or coloured
red.
_ terminal marked ‘N’ or
_ coloured black.
NOTE: CE marking certifies that this appliance
__ complies with the requirements laid down in
__ EEC Directive 89:336 (Electromagnetic
_
compatibility)
and
subsequent
modifications
and
Low
Voltage
direction
73/23/EEC.
This appliance should be connected to the mains supply via a
suitable switched socket in an accessible position.
WARNING: THIS APPLIANCE
MUST BE EARTHED.
Your appliance comes fitted with a plug and a 13A fuse. If you
need to replace the fuse, only those rated at 13A and ASTA
approved to BS1362 should be used.
The fuse cover MUST be re-fitted after changing the fuse.
WARNING: DO NOT USE THE PLUG UNLESS THE
FUSE COVER IS FITTED.
lf you lose the fuse cover, a replacement may be obtained from
an authorised Service Centre (see list supplied), or an
Electricity company.
The correct replacement is identified by the colour coding, or
marking on the base of the plug.
If the plug does not fit your socket, you can cut it off and
dispose of it.
WARNING: DO NOT INSERT THIS PLUG INTO A
SOCKET ELSEWHERE AS THIS COULD CAUSE A
SHOCK HAZARD.
IMPORTANT: THE WIRES IN THE MAINS LEAD ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
Green/Yellow — Earth
Blue — Neutral
Brown — Live
If you change the plug, the colours of the wires in the mains
lead may not correspond with the colours of the markings
identifying the terminals in the plug. You should therefore wire
it as shown (see illustration).
if the mains lead needs to be replaced at any time, it should be
replaced by a special lead obtainable from your local
authorised Service Centre. A charge will be made if you have
damaged the existing lead or require a longer one.
It is strongly advised that this work is carried out by a qualified
electrician.
