TempTronic RC
Operating Manual
Art. No. 4 206 403-en-00 / Page 3
Basic Principles3
Operating elements3.1
The unit is operated via a 4-line display and 4 keys:
TempTronic RCFig. 1:
Key Action
Navigation to the left ●
Start up screen: access to the main menu ●
Acknowledge values ●
Navigation to the right ●
Start up screen: direct access to submenu ●
'Operating mode'
Increase values ●
Navigation in upward direction ●
Reduce values ●
Navigation in downward direction ●
not in use ●
Assignment of keysTable 2:
