PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
ATTACHING THE HANDLEBARS
Attach the handle bars by placing them into the appropriate sockets and
twisting them counter-clockwise.
NOTE: If the handlebars do not attach lush to the frame, you may need to shift
the location of your throttle and brake assembly. Loosen the throttle and brake
assembly with the included hex key and make sure they are NOT touching or
blocking your handlebars, then tighten them.
• Ensure that the charging port is clean and dry.
• Make sure that there is no dust, debris or dirt inside the port.
• Plug the charger into a grounded wall outlet.
• Connect the cable with the power supply (100V240V; 50 Hz/60 Hz).
• Align and connect the 1-pin charging cable into the charging port of the
Edge 2.0 (DO NOT FORCE OR BEND THE CHARGING CABLE AS IT MAY
CAUSE THE PRONGS TO BEND OR BREAK).
• The charging indicator light on the charger itself should change to red,
indicating that your device is now being charged.
• When the red indicator light on your charger turns to green, then your
device is fully charged.
• After fully charging your Edge 2.0, unplug the charger from your device
and from the power outlet
Only use the included charging
cable and charger to charge your
Edge 2.0. Using any other charger
may damage your Edge 2.0.
CAUTION
CHARGING YOUR EDGE 2.0
PREPARING YOUR E-SCOOTER
COUNTER-CLOCKWISE COUNTER-CLOCKWISE
18
