23
7.3 DISMANTLING PROCEDURE FOR ANNUAL INSPECTION (Continued)
Removing the Combined Outlet Cover/Cylinder 163 Compressor
Fit an eyebolt to the tapped hole at the top of the outlet cover, attach a sling to the eyebolt to support
the weight of the cover (Fig. 7).
Fig. 6 Fig. 7
