RECOMMENDED SPARES LIST
HOWDEN COMPRESSOR MODELS: Mk6 & 6A 6B WRVi 255/110, 130, 145, 165, 193
 Replacement Shaft Seal Kit – KS255-6
PART NUMBER
DESCRIPTION
QUANTITY
KWS255-6
Input Shaft Seal c/w Cover ‘O’ Ring
1
 Annual Inspection Kit – KW255-6
PART NUMBER
DESCRIPTION
QUANTITY
G26019
Tuflock Screw ¼” UNC x ⅝” LG
6
G32009
Straight Tab Washer ⅜”
8
G32013
Straight Tab Washer ⅝”
6
VR25500-BK
Bonded Seal Kit containing:
G33001 – Bonded Seal ⅜” BSP
6
G33003 – Bonded Seal ¾” BSP
3
G33004 – Bonded Seal 1” BSP
2
G33005 – Bonded Seal 1-¼” BSP
2
G33008 – Bonded Seal ¼” BSP
4
G51001
Ball Bearing (Actuator Spindle)
1
G55012
Gasket – S/Feed
1
Q5163
Lockwasher 40mm (Piston)
1
R25125
PTFE Ring (Actuator Piston)
1
R25135
Adjusting Washer (Thrust Bearings)
6
R25883
Rotor Locking Plate
2
G60009
Circlip (Journal Bearings)
4
G60086
Circlip (Vi Adjuster)
1
M0702016
Spring Washer – 16 Dia.
56
R25145
PTFE Ring (Piston Rod / Guide Bracket)
1
VR25101 - OK
‘O’ Ring Kit containing:
G44001 – ‘O’Ring (Piston Rod)
1
G44002 – ‘O’Ring (Piston)
1
G44005 –‘ O’Ring (Ind. Spindle)
1
G44008 – ‘O’Ring (Casing)
2
G44020 – ‘O’Ring (Cylinder. Spigot)
1
G44070 – ‘O’Ring (Covers)
3
G44075 –‘ O’Ring (Act. Cylinder.)
2
M6000269 –‘ O’Ring (Cylinder. Flange.)
1
M6002962 – ‘O’Ring (Vi Spindle)
2
M6009453 – ‘O’Ring (Cover)
1
G60004
Retaining Ring (Actuator spindle – Outer)
1
G60005
Retaining Ring (Actuator spindle – Inner)
1
Suction and Discharge joints are not part of Inspection Kit. These are available at extra cost as
required.
 Replacement Thrust Bearing Kit – KWT255
PART NUMBER
DESCRIPTION
QUANTITY
G51035
Angular Contact Bearing
4
 Replacement Journal Bearing Kit – KWJ255
PART NUMBER
DESCRIPTION
QUANTITY
R25663
Inlet End Journal Bearing
2
R25643
Outlet End Journal Bearing
2
G36005
Dowel Pin
4
Note: For Viton or Fluorosilicone ‘O’ Rings please contact:
Howden Compressors Limited, Compressor Business Unit, 133 Barfillan Drive, Glasgow, G52 1BE, UK
Telephone: +44 (0)141 882 3346 Fax: +44 (0)141 882 8648
