Heat sink assembly

NOTE: The heat sink assembly spare part kit includes replacement thermal materials.

Description Spare part number

Heat sink for use in models with discrete graphics memory and Intel Core processors 815238-001

Heat sink for use in models with UMA graphics memory and Intel Core processors (except for Pentium

N3540)

815237-001

Heat sink for use in models with discrete graphics memory and Intel Pentium or Celeron processors 816604-001

Heat sink for use in models with UMA graphics memory and Intel Pentium or Celeron processors 816603-001

Heat sink for use in models with UMA graphics and an Intel Pentium N3540 processor 833733-001

NOTE: To properly ventilate the computer, allow at least 7.6 cm (3.0 in) of clearance on the left side of the

computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature sensor and

is designed to turn on automatically when high temperature conditions exist. These conditions are aected by

high external temperatures, system power consumption, power management/battery conservation

congurations, battery fast charging, and software requirements. Exhaust air is displaced through the

ventilation grill located on the left side of the computer.

Before removing the heat sink assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the battery (see Battery on page 32).

5. Remove the optical drive (see Optical drive on page 33), if installed.

6. Remove the bottom cover (see Bottom cover on page 39).

To remove the heat sink assembly:

1. Refer to the following heat sink removal image that matches your computer.

2. Loosen the screws on the heat sink that secure the heat sink assembly to the system board.

Component replacement procedures 51
