Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part
number
(2) Camera module
NOTE: The camera module thermal pad is available as spare part number
N15691-001.
N15690-001
(3) Display hinges (includes left and right hinges) N15693-001
(4) Display hinge covers (left and right hinge covers)
Natural silver N15694-001
Space blue N15695-001
(5) Touch control board
NOTE: The touch control board is included in the touch panel spare part kits.
not available as a
spare part
(6) Ambient light sensor board
NOTE: The ambient light sensor is included in the touch panel spare part kits.
The ambient light sensor cable is available as spare part number N15698-001.
not available as a
spare part
(7) WLAN antenna kit (includes antenna cables and transceivers)
OLED models N15677-001
LCD models N17069-001
(8) Display cable
QHD display N22067-001
FHD display N22068-001
OLED display N15697-001
(9) Touch control board cable N15699-001
(10) Display back cover
OLED, natural silver N15673-001
OLED, space blue N15674-001
LCD, natural silver N15675-001
LCD, space blue N15676-001
* Display panel adhesive N15689-001
*not illustrated
26 Chapter 3Illustrated parts catalog
