b. Disconnect the cable (2) from the camera/microphone module.
The HD camera module is available using spare part number L20447-001. The VGA camera module
is available using spare part number L20446-001.
4. If it is necessary to replace the display panel:
IMPORTANT: HD panels are secured to the display enclosure with screws. FHD panels are secured with
tape.
a. HD panels:
Remove the four Phillips M2.0×3.0 screws that secure the panel to the display enclosure.
64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
