b. Remove the display bezel (4).
NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
2. To remove the webcam/microphone module:
a. Position the display assembly with the top edge toward you.
b. Disconnect the cable (1) from the module.
c. Remove the webcam/microphone module (2). (The module is attached to the display enclosure
with double-sided tape.)
3. To remove the display panel:
a. Remove the four Phillips PM2.5×3.5 screws that secure the display panel to the enclosure.
Component replacement procedures 73
