NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
b. Rotate the display panel onto the keyboard to gain access to the display cable connection on the
back of the panel (1).
c. On the back of the display panel, release the adhesive strip (2) that secures the display panel cable
to the display panel, and then disconnect the cable (3).
NOTE: In this procedure, the display will NOT be connected to the computer, as shown in the
following image.
4. To remove the display hinges:
74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
