HP 2230s - Compaq Business Notebook Setup Guide

Restoring factory settings in Computer Setup
NOTE: Restoring defaults will not change the hard drive mode.
To return all settings in Computer Setup to the values that were set at the factory, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
2. Press f10 to enter BIOS Setup.
3. Use a pointing device or the arrow keys to select File > Restore defaults.
4. Follow the on-screen instructions.
5. To save your changes and exit, click the Save icon in the lower-left corner of the screen, and then
follow the on-screen instructions.
– or –
Use the arrow keys to select File > Save changes and exit, and then press enter.
Your changes go into effect when the computer restarts.
NOTE: Your password settings and security settings are not changed when you restore the factory
settings.
4 Chapter 2 Using Computer Setup

HP 2230s - Compaq Business Notebook Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Operating System	Windows Vista Business
Battery	6-cell Lithium-Ion
Screen Resolution	1280 x 800
Storage	Up to 250GB HDD
Graphics	Intel GMA X3100
Weight	1.59 kg
Chipset	Intel GM965 Express
Optical Drive	DVD±RW
Wireless	802.11a/b/g
Bluetooth	Bluetooth 2.0
Audio	High Definition Audio
Ports	3 USB 2.0, VGA, RJ-45, headphone/microphone jacks
Card Reader	5-in-1
Webcam	Optional
