HP 255 G5 - Display assembly

Display assembly
This section describes removing the display assembly and disassembling display subcomponents. You must
remove the display from the computer to disassemble display subcomponents.
Description Spare part number
Raw display panel (39.6-cm [15.6-in])
For use in HP Notebook PC models
●
FHD, for use in models with a non-touch screen (anti glare) 798933-007
●
HD, for use in models with a non-touch screen (anti glare) 909185-002
●
HD, for use in models with a touch screen (BrightView) 847654-003
●
HD, for use in models with a non-touch screen (BrightView) 809612-010
For use in HP Notebook PC and HP 255 G5 Notebook PC models:
●
FHD 864127-001
●
HD 864128-001
Antenna (includes wireless antenna cable and transceiver)
Single 854985-001
Dual 854986-001
Display bezel 855000-001
Display cable
For use in non-touch screen models (includes display panel cable and webcam/microphone cable) 813943-001
For use in touch screen models (includes display panel cable and webcam/microphone cable) 813944-001
Display enclosure for use in all HP Notebook PC models:
Black models 854992-001
Red models 854989-001
White silver models 854988-001
Turbo silver models 854987-001
Noble blue models 854991-001
Teal models 854990-001
Iris purple models 901745-001
Powder blue models 908025-001
Soft lilac models 908026-001
Misty green models 908027-001
Display enclosure for use in HP 255 G5 Notebook PC models:
Black models 859511-001
Silver models 905913-001
Hinges (left and right) 855006-001
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
