5. Separate the display from the computer (3).
If it is necessary to replace any of the display assembly subcomponents:
1. To remove the display bezel:
a. Flex the inside of the top edge (1), the left and right edges (2), and the bottom edge (3) of the
display bezel until the bezel disengages from the display enclosure.
b. Remove the display bezel (4).
2. To remove the webcam/microphone module:
68 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
