138 Removal and replacement
EN
4 Remove the self-tapping screw (callout 1) that holds the feed
assembly in place.
Note Before proceeding, examine the tabs and how they fit into their slots
(callout 2). The tabs must be reinstalled to exactly this position.
5 Remove the feed assembly.
Figure 66. Feed assembly removal (2 of 3)
