Common hardware
229
Table 31. Internal components (2 of 3)
Reference Part number Description
1 RY7-5005-000CN Gear kit #1
2 RB1-7288-020CN Bushing (2)
3 RB1-7105-000CN Pressure release lever
4 RB2-1632-000CN Gear support plate
5 RB1-7107-000CN Gear holder
6 RY7-5007-000CN Fuser release kit
7 RH7-1320-000CN Motor, DC 12V
8 RY7-5036-000CN Gear kit #2
16 RG5-3453-000CN Switch lever assembly
17 RF5-2367-000CN Exit roller
Note:
The Following two parts (ref. 19 and 20) must
both
be replaced if replacing either one.
19 RG5-3497-050CN Laser/scanner assembly
20 RB1-7385-020CN Grounding spring
21 XA9-0267-000CN Screw, TP, M3X6 (2)
22 XA9-0382-000CN Screw, TP, M3X12
23 WE8-5192-000CN Ferrite ring core
24 RB9-0227-000CN Spacer
501 XB6-7300-807CN Screw, TP, M3X8 (5)
502 XB4-7300-809CN Screw, tapping, truss head, M3X8
