Common hardware
235
Table 34. Paper pickup assembly
Reference Part number Description
RG5-3484-070CN Paper pickup assembly
RG5-3485-030CN Feed assembly
RG5-3486-040CN Pickup roller assembly (
Note:
if replacing this part,
also replace the separation pad kit, part number
RY7-5008-000CN)
1 RB1-7172-000CN Spring, grounding
2 RY7-5008-000CN Separation pad kit (
Note:
if replacing this part, also
replace the pickup roller assembly, part number
RG5-3486-040CN)
3 RY7-5009-000CN Input sensor assembly
5 RB1-7184-000CN Bushing
6 RB1-7197-020CN Clutch
7 RB1-7199-000CN Spring, grounding
9 RG5-1947-000CN Paper feed drive assembly
13 RH7-5139-000CN Solenoid
14 RS5-2501-000CN Spring, compression
16 RB1-7185-000CN Arm, plate, left
17 RB1-7186-000CN Arm, plate, right
18 RF5-2372-000CN Plate, middle
20 RB1-7177-000CN Frame, paper feed
501 XB4-7401-000CN Screw, tapping, pan head, M4X10 (2)
