244 Parts and diagrams
EN
ECU, 110 V RG5-4690-000CN 95 18
ECU, 220 V RG5-4691-070CN 95 18
Exit roller RF5-2367-000CN 93 17
Face-up/face-down lever RG5-3476-000CN 98 2
Feed assembly RG5-3485-030CN 96, 97
Feed roller RB2-1699-000CN 97 1
Ferrite ring core WE8-5192-000CN 93 23
Fixing assembly, 110 V RG5-4678-000CN 94 16
Fixing assembly, 220 V RG5-4681-000CN 94 16
Foot (4) RF5-2663-000CN 95 4
Formatter—LJ 3100 C3949-60001 92 22
Formatter—LJ 3100 (exchange) C3949-69001 92 22
Formatter—LJ 3150 C3949-60002 92 22
Formatter—LJ 3150 (exchange) C3949-69002 92 22
Frame, paper feed RB1-7177-000CN 96 20
Front casing RB2-3449-000CN 88 6
Fuser connector (2P) VS1-5057-002CN 94 15
Fuser exit roller assembly RF5-2368-000CN 98 7
Fuser release kit RY7-5007-000CN 93 6
Fuser roller bushing RB2-1690-000CN 98 4
Gear holder RB1-7107-000CN 93 5
Gear kit #1 RY7-5005-000CN 93 1
Gear kit #2 RY7-5036-000CN 93 8
Gear support plate RB2-1632-000CN 93 4
Grounding clip RB1-7223-000CN 94 1
Grounding metal RB1-7129-000CN 94 8
Grounding plate RB2-4118-000CN 92 12
Grounding plate (2) RB2-3467-000CN 92 13
Grounding spring RB1-7385-020CN 93 20
Guide sheet RB1-7176-000CN 92 11
I/O bezel C3948-40010 88 1
Table 38. Alphabetical parts list
Part name Part number Figure # Reference
