HP 400D Organizational, Ds, Gs, And Depot Maintenance Manual

TM 11-6625-1514-15
Section VII
Group Assembly Parts List
FIG. &
H-P MFR. OR MIL
DESCRIPTION
UNITS
INDEX
STOCK
PART
PER
NO.
NO. NO.
1234567
ASSY
7-1-
NO NUMBER . PANEL ASSEMBLY, FRONT
1
(ATTACHING PARTS)
2520-0003 AN526-832-8 .
SCREW, MACHINE . . . . . . . . . . . .
5
2580-0003 510-081810-01 . NUT, ASSEMBLIED WASHER (78189) . .
1
---*---
-2
5060-0634
5060-0634 . .
POST, BINDING, Red (28480) . . . .
2
-3
5060-0635 5060-0635 . . POST, BINDING, Black (28480) . . .
2
-4 0340-0089
0340-0089
.. INSULATOR, STANDOFF (28480) . .
2
-5
0340-0090
0340-0090 . . INSULATOR, STANDOFF (28480) . . 2
-6 1450-0020
14L-15
. . LENS, INDICATOR LIGHT (72765) .
1
-7 2140-0012
12 . .
LAMP, INCANDESCENT, 6-8 VOLT,
1
2 pin base (93519)
-8
1450-0022
2020-AE
. .
LAMPHOLDER, 2 pin base (72765) .
1
-9 3101-0001
80994-H
. .
SWITCH, TOGGLE, SPST (04009) . .
1
-10 0370-0035 0370-0035 .. 1
-11 (D, H02) 1120-0005
1120-0005
.. MULTIMETER, REPLACEMENT . .
1
(28480)
(H)
1120-0301
1120-0301
. . MULTIMETER, REPLACEMENT . .
1
(28480)
(L) 1120-0098
1120-0098 . .
MULTIMETER, REPLACEMENT . .
1
(28480)
-12 1400-0015
1550 ..
CLAMP, LOOP (73734) . . . . . . .
1
-13 5020-0137
5020-0137
. . BEZEL, INSTRUMENT MOUNTING 1
(28480)
(ATTACHING PARTS)
2360-0003
AN515-6-4
. .
SCREW, MACHINE . . . . .
6
---*---
-14 (D, H02) 400D-2 400D-2 . .
PANEL, FRONT (28480) . . . . . . .
1
(H, L)
400H-2A
400H-2A
.
PANEL, FRONT (28480) . . . . . . .
1
-15 NO NUMBER .
MAIN CHASSIS ASSEMBLY . . . . .
1
(See figure 7-2) (28480)
KNOB (28480)
7-2
00102-3
