Getting Started
Making a Measurement
Step 6. Set up the results display
You set the results display information on the DISPLAY: DISPLAY SETUP page.
1. Press
4
Display
5
front-panel key. The DISPLAY: DISPLAY SETUP page
appears.
DISPLAY: DISPLAY SETUP page
DISPLAY MODE
2. Make sure
GRAPHICS
is displayed in the DISPLAY MODE eld. If not,
select
NNNNNNNNNNNNNNNNNNNNNNN
GRAPHIC
secondary softkey in the DISPLAY MODE eld.
3. Set the X-, Y1-, and Y2-axes information as follows:
14
