8. Turn the computer display-side up, and then remove the 2 screw covers and screws from the back
edge of the computer.
9. Open the computer as far as possible.
CAUTION: Do not use excessive force to open the computer beyond the limits of the display
hinges. Forcing extension beyond these limits will cause damage to the display.
10. Slide the switch cover straight back towards the display, and then remove the switch cover.
21
