126 ENWW
Replacing supplies
Locating supplies
Supplies are identified by their labeling and their blue plastic handles.
The following figure illustrates the location of each supply item.
Supply item locations
1. fuser
2. print cartridges
3. transfer unit
Supply replacement guidelines
To facilitate the replacement of supplies, keep the following guidelines
in mind when setting up the printer.
z Sufficient space is required above and in the front of the printer
for removing supplies.
z The printer should be located on a flat, sturdy surface.
WWW For instructions on installing supplies, see the installation guides
provided with each supply item or see more information at
http://www.hp.com/support/lj4600
. When you connect, select Solve a
Problem.
1
1
1
3
1
2
