HP 5087A - Replaceable Parts

Model 5087A
Replaceable Parts
See introduction to this section for ordering information
*Indicates factory selected value
6-13
Table 6-2. Replaceable Parts (Continued)
Reference
Designation
HP Part
Number
C
D
Qty Description
Mfr
Code
Mfr Part Number
A14 05087-60014 1 1 BOARD, 1O-TO-1-MHZ DIVIDER (OPT 014)
(SERIES 1240)
28480 05087-60014
A14C1 0150-0093 0 3 CAPACITOR-FXD 0.01UF +80-20% 100VDC 72982 801-K800011
A14C2 0140-0198 3 2 CAPACITOR-FXD 200PF 5% 72136 RMD15F201J3C
A14C3 0150-0093 0 CAPACITOR-FXD 0.01UF +80-20% 100VDC 72982 801-K800011
A14C4 0180-0116 1 1 CAPACITOR-FXD 6.8 UF 10% 35VDCW 56289 150D685X903582-DYS
A14C5 0180-0117 2 3 CAPACITOR-FXD 2.7UF 10% 35VDCW 28480 0180-0117
A14C6 0180-0117 2 CAPACITOR-FXD 2.7UF 10% 35VDCW 28480 0180-0117
A14C7 0140-0198 5 CAPACITOR-FXD 200PF 5% 72136 RMD15F201J3C
A14C8 0140-0196 3 1 CAPACITOR-FXD 150 PF 5% 28480 0140-0196
A14C9 0150-0093 0 CAPACITOR-FXD 0.01UF +80-20% 100VDC 72982 801-K800011
A14C10 0140-2224 2 1 CAPACITOR-FXD 1800PF 5% 28480 0140-2224
A14C11 0180-0117 2 CAPACITOR-FXD 2.7UF 10% 35VDCW 28480 0180-0117
A14CR1 1901-3104 4 1 DIODE-BREAKDOWN 5.62V 5% 04713 SZ10939-110
A14CR2 1901-0040 1 2 DIODE 50 MA 30 MV 07263 FDG1088
A14CR3 1901-0040 1 DIODE 50 MA 30 MV 07263 FDG1088
A14L1 9140-0138 2 1 COIL-CHOKE 180UH 5% 28480 9140-0138
A14L2 9100-0129 7 1 COIL-CHOKE 220 UH 5% 28480 9100-0129
A14L3 9100-2282 7 1 COIL-CHOKE 330 UH 5% 99800 9100-2282
A14Q1, Q2, Q4 1854-0477 7 3 TRANSISTOR SS 2N2222A 28480 1854-0477
A14Q3 1854-0003 5 1 TRANSISTOR NPN 28480 1854-0003
A14R1 0757-0893 4 1 RESISTOR 51 OHM 2% 1/8W 28480 0757-0893
A14R2 0757-0939 9 1 RESISTOR 4.3K OHM 2% 1/8W 28480 0757-0939
A14R3 0757-0932 2 1 RESISTOR 2.2K OHM 2% 1/8W 28480 0757-0932
A14R4 0757-0920 8 1 RESISTOR 680 OHM 2% 1/8W 28480 0757-0920
A14R5 0757-0931 1 1 RESISTOR 2K OHM 2% 1/8W 28480 0757-0931
A14R6 0757-0928 6 1 RESISTOR 1.5K OHM 2% 1/8W 28480 0757-0928
A14R7 0757-0908 2 2 RESISTOR 220 OHM 2% 1/8W 28480 0757-0908
A14R8 0757-0923 1 1 RESISTOR 910 OHM 2% 1/8W 28480 0757-0923
A14R9 0757-0943 5 1 RESISTOR 6.2K OHM 2% 1/8W 28480 0757-0943
A14R10 0757-0934 4 1 RESISTOR 2.7K OHM 2% 1/8W 28480 0757-0934
A14R11 0757-0917 3 2 RESISTOR 510 OHM 2% 1/8W 28480 0757-0917
A14R12 0757-0908 2 RESISTOR 220 OHM 2% 1/8W 28480 0757-0908
A14R13 0757-0917 3 RESISTOR 510 OHM 2% 1/8W 28480 0757-0917
A14T1 107A-9H 6 1 TRANSFORMER ASSY, 1 MHZ 28480 107A-9H
A14U1 1820-0055 6 1 IC TTL DECADE COUNTER 10 MHZ MIN 01295 SN7490N
8159-0005 0 1 JUMPER 28480 8159-0005
