HP 5200 Series

Walkaround
Printer parts
Before using the printer, familiarize yourself with the parts of the printer.
5
1
2
3
4
7
6
1 Top output bin
2
Long-media extension
3 Latch to open the front cover (provides access to the print cartridge)
4 Tray 1 (pull to open)
5
Tray 2
6 Control panel
7
Right-side cover (provides access to DIMMs and CompactFlash cards)
