Model 5334A
General Information
I-20. Instruments having a lower serial number prefix than that listed on the title page, are
wvercd in Section VII of lhe HP 5334A Operating and Service manual. For information con-
cerning an instrument with a serial number prefix that is not listed on the title page or in the
Manual Changes, contact your nearest Hewlett-Packard Sales and Service Office.
I-21. DESCRIPTION
l-22. The HP5334A isaUniveriaICounter(:apableof mcasuringsignalsupto100MHz. Withthe
Optional C Channel this capability is extended to 1.3 GHz. The instrument’s basic measurement
functions ,include Frequency, Period, ‘Time, Time Delay, Ratio, and Totalize. The resident
Multiple Register Counter IMRCI and three single chip microprocessors used to generate data,
compute and display answers, expand the usefulness of the counter by providing post
measurcmcnt data manipulation. This allows the additional power and convenience of user-
defined ~measurement function keys for Math Functions, Pulse Width, Rise/Fall Time, and
voltage peaks of
the
input signal and includes a nonvolatile memory that provides the capability
to save and recall up to nine different front panel set-ups.
l-23. The HP 5334A front-end provides two independent input channels, featuring matched
high perfvrmancc 100 MHz input amplifiers. Each input channel includes a full complement of
input signal conditioning controls, in addition to extensive triggering and arming control. Most
rneasurernents are displayed in engineering notation. Analog interpolation provides 9 digits of
resolution in one-second of gate time. Gate timesare keyboard-selectable from 1 millisecond to
1000 seconds in millisecond increments.
l-24. lull HP-IB programmability is a standard feature of the HP 5334A Universal Counter. All
front-panel features including gate time, trigger levels and sensitivity may be sclccted via HP-IB.
HP-IB provides remote control of programming and data output.
I-25. ACCESSORIES
1.26. ‘lable I-Z lists accessory equipment supplied with the HP 5334A Universal Counter and
Table 1-3 lists accessories available.
Table 1-2. Equipmolr Supplied
DESCRtPTtoN
HP PART NUMBER
Detachable Power Cord
229 cm rw2 feet longI
0120.1378
DESCRlPTlON
I
HP PART NUMBER
Rack Mounting Adaprcr Kits:
Kxk Mount with Handles attached
Rack Mount with Handles removed
2 1300 MHz Preamplifiers
ILow Pass Filter Kit
I’robes:
500 MHz Acfivt
‘Time lnfrrval
1U:l Divider
Resistive Divider
5020-8874
5020.8862
lOR55A
10856A
1120A
53630
10001A
10020A
