HP 5335A Service Manual

Table 1-1. Specifications
INPUT CHARACTERISTICS
(Channel A and B)
Range:
DC coupled, 0 to 100 MHz.
AC 1 Mn, 30 Hz io 100 MHz.
AC 50 SI, 200 KHz to 100 MHz.
NOTE : Channel A range 200 MHz when
in Frequency A and Ratio modes.
Sensitivity (XI);
25 mV rms sine wave.
75 mV peak-to-peak pulse at minimum
pulse width of 5 ns.
Dynamic Range (XI):
75 mV to 5V peak-to-peak, to 100 MHz.
75 mV to 2.5V peak-to-peak, > 100 MHz.
Signal Operating Range (Xi, DC);
-5V dc to +5V dc.
Crosstalk (XI): < 500 mV rms, 0 to 100 MHz.
or < 250 mV rms, 100 to 200 MHz, sine wave in
either channel will not affect other channel.
Trigger Level Range (XI):
Auto Trigger OFF:
Preset: Set to OV dc NOMINAL.
Adjustable: ~5V dc to 45V dc.
Auto Trigger ON:
Preset: Set to NOMINAL 50% point of
input signal.
Adjustable: NOMINALLY between 4 and -
peaks of input signal.
Auto Trigger (XI):
Range (50% duty cycle):
DC coupled, 30 Hz to 200 MHz.
AC 1 MV, 30 Hz to 200 MHz.
AC 50 (1, 200 kHz to 200 MHz.
Minimum Signal: 100 mV rms.
Duty Cycle Range: 10% to 90%.
Response Time: 3 seconds TYPICAL.
NOTE: Auto Trigger requires a repetitive
signal.
Coupling: AC or DC, swilchable.
Impedance: 1 Mfl NOMINAL shunted by
< 35 pf, or 50 n NOMINAL, swifchable. In
COMMON A, 1 Mf! is shunted by < 50 pf.
Attenuator: XI or X10 NOMINAL, swilchable.
Slope: Independent selection of + or - slope.
Channel Input: SEPARATE or COMMON A,
swilchable.
Damage Level (AC or DC):
1 Mfl X I:
DC to 2 kHz . 250V (DC 4 AC rms)
2 to 100 kHz .... (5 X 10 5 V rms Hz) /FREQ
> 100 kHz . 5V rms
i Mn x io.
DC to 20 kHz . 250V (DC + AC rms)
20 to 100 kHz ... (5 X 10 6 V rms Hz) ./FREQ
> 100 kHz . 50V rms
500;
DC to 200 MHz. 5V rms
FREQUENCY A
Range: 0 to 200 MHz, prescaied by 2.
LSD** Displayed:
pR£Q (e.g.. 9 digits in a second)
Resolution:
: (2X LSD) ± 1.4X
'trigger Error*
Gate Time
Accuracy: i (Resolution) ± (Time Base Error)
X FREQ.
PERIOD A
Range: 10 ns io SO' s.
LSD** Displayed:
1 DS
7.-,. ~=s~- .- X PER. (e.g , 9 digits in a second)
Gate lime
Resolution:
: (2 X LSD): .4 X XPER.
Gate Time
Accuracy: ±(Resolution) ±(Time Base Error)
X PER.
Period Average: User selects MEAN (unction, and
n = 100, or n = 1,000.
TIME INTERVAL A—B
Range: 0 ns to 10 7 S.
LSD** Displayed: 1 ns U00.ps using MEAN)
Resolution: ± (2 X LSD) ± (START Trigger Error**}
± (STOP Trigger Error**).
Accuracy: ± (Resolution) ± (Time Base Error) X
Tl 1 (Trigger Level Timing Error**) ± (2 ns).
Gate Mode: MIN only.
Time Interval Average: User selects MEAN func¬
tion, and n = 100, or n - 1,000.
TIME INTERVAL DELAY (Hoidoff)
For Time A---B, 1/Time A--B, Pulse A, (Time
B -A, Pulse B), front pane! Gate Adjust control
inserts a variable delay between START and
enabling of STOP. Electrical inputs during delay
are ignored. Delay ranges are same as gate time
ranges (100 ns to 4s NOMINAL) for gate modes
of Fast, Norm, and Manual. Delay measured by-
pressing Gate Time key. All other specifications
are same as Time interval A—B.
INVERSE TIME INTERVAL A—B
Range: 10 ' to 10^ units/second.
LSD Displayed, Resolution, and Accuracy are
inverse of Time interval A-B specifications. If
Time Interval A—B is zero, display will be zero.
RISE AND FALL TIME A
Range: 20 ns to 10 ms transitions with 50 Hz to
25 MHz repetition rates (50% duty cycle).
Minimum Pulse Height: 500 mV peak-to-peak.
Minimum Pulse Width: 20 ns.
Duty Cycle Range: 20% So 804,
LSD Displayed and Resolution are same as
Time Interval A-B specifications.
Accuracy: ± (Tl Accuracy) ± (Trigger Level
Setting Error** at 10% point) ± Trigger Level
Setting Error** at 90% point).
Input Mode: Automatically set to COMMON A
with 10% and 90% trigger ieveis.
Gate Mode: MIN only.
PULSE WIDTH A
Range: 5 ns to 10's.
Trigger Point Range: 40% to 60% oi pulse height
LSD Displayed and Resolution are same as
Time Interval A -B specifications.
Accuracy: ± (Resolution) ± (Time Base Error)
X PULSE ± (Trigger Level Timing Error**} ± 2 ns.
DUTY CYCLE** A
Range: 1% Io 99%, 0 to 100 MHz.
Trigger Point Range: 404, to 604, of pulse height.
LSD** Displayed:
~~~~ X 1004,
PER
Resolution:
PULSE + I PULSE Resolution j „ ..
PER - | PER Resolution j
- DUTY CY).
Accuracy:
+ PULSE + J PULSE Accuracy ! y y
- ! per -HPER Accuracy! * W
■■■ DUTY CY).
Gate Mode: MIN only.
NOTE: Constant duty cycle required during
measurement.
SLEW RATE** A
Range: 50 V/s to 10 s V/s slew rate with 50 Hz to
25 MHz repetition rates (50% duty cycle).
Minimum Pulse Height, W f idth, and Duty
Cycle Range are same as Rise and Fall Time A.
LSD** Displayed:
TRISETATTT ^ SLEW; three digits maximum.
Resolution:
+ I TRIG LVL B - TRIG LVL A + 20 mV
- TRISE/FaIL! - 1 RISE/FALL Resolution!
- 1 SLEW (
Accuracy:
. 1 TRIG LVL B - TRIG LV L AJ X 1.003 4 40 mV
"" ' : RISE/FALL f - | RISE/FALLAccuracy i
- | SLEW j).
Input Mode: Automatically set =0 COMMON A
with IO", and 90% trigger levels.
Gate Mode: MIN only.
RATIO A/B
Range:
Channel A, 0 to 200 MHz {prescaled by 2).
Channel B. 0 to 100 MHz.
LSD** Displayed:
RATIO
'FREQ x Gate fime ’
where FREQ is higher frequency after prescaling.
Resolution:
± LSD ± x RAT |o t
where Trigger Error is on lower
frequency after prescaling.
Accuracy: Same as Resolution
TOTALIZE A
Range: 0 to 100 MHz.
LSD** Displayed: 1 count of input
HP-IB Output: At end of gate
Manual:
Count Reset: Via RESET key.
HP-IB Output; Totalize data on the-fly sent
if Cycle mode set to Single. Input frequency
range in this mode is 0 to 50 Hz NOMINAL.
Gated:
Count Reset: Automatic after measurement
Resolution: ± LSD
Accuracy: Same as Resolution
‘Specifications describe the instrument’s warranted performance. Supplemental characteristics are intended to provide information useful in applying the instrument by
giving TYPICAL or NOMINAL, but nonwarranted performance parameters. Definition of terms is provided at the end of the specification section. For a more detailed
explanation, see Application Note 200-4 “Understanding Frequency Counter Specifications”.
**See Definitions section for further information.
General Information

HP 5335A Specifications
