TM 11-6625-2958-14&P
SECTION VI
REPLACEABLE PARTS
6-1 INTRODUCTION
6-2 This section contains information for ordering
replacement parts. Table 6-4 lists parts in alpha-
numeric order by reference designators and provides
the following information:
a.
Reference Designators. Refer to Table 6-1.
b. Description.
Refer to Table 6-2 for ab-
breviations.
c. Total Quantity (TQ). Given only the first
time the part number is listed except in instruments
containing many sub-modular assemblies, in which
case the TQ appears the first time the part number
is listed in each assembly.
d. Manufacturer’s Part Number or Type.
e.
Manufacturer’s Federal Supply Code Num-
ber. Refer to Table 6-3 for manufacturer’s name and
address.
f. Hewlett-Packard Part Number.
g. Recommended Spare Parts Quantity (RS)
for complete maintenance of one instrument during
one year of isolated service.
h. Parts not identified by a reference desig-
nator are listed at the end of Table 6-4 under Me-
chanical and/or Miscellaneous.
The former consists
of parts belonging to and grouped by individual as-
semblies; the latter consists of all parts not im-
mediately associated with an assembly.
6-3 ORDERING INFORMATION
6-4 Table 6-5 is a part number-national
stock number cross reference index.
The
items on this cross reference index are
source coded PAHZZ. Items that do not
appear on this cross reference index are
source coded XD and shall be procured
using the FSCM and the NPN at the near-
est wholesale level.
Table 6-1. Reference Designators
A
= assembly
E
= miscellaneous
B
= blower (fan)
electronic part
C
= capacitor
F = fuse
CB
= circuit breaker
J
= jack, jumper
CR
= diode
K
= relay
DS
= device, signal- L
= inductor
ing (lamp)
M = meter
Table 6-1.
Reference Designators (Continued)
P
= plug
Q
= transistor
R
= resistor
s = switch
T
= transformer
TB
= terminal block
TS
= therms 1 switch
v . vacuum tube,
neon bulb,
photocell, etc.
VR
= zener diode
x
= socket
z
= integrated cir-
cuit or network
Table 6-2. Description Abbreviations
A
= ampere
ac
= alternating
current
ass y.
= assembly
bd
= board
bkt = bracket
°C
= degree
Centigrade
cd
= card
coef
= coefficient
comp
= composition
CRT
= cathode-ray
tube
CT
= center-tapped
dc
= direct current
DPDT = double pole,
double throw
DPST = double pole,
single throw
elect = electrolytic
encap =
encapsulated
F
= farad
OF
= degree
Farenheit
fxd
= fixed
Ge
= germanium
H
= Henry
Hz
= Hertz
IC
= integrated
circuit
ID
= inside diameter
incnd =
incandescent
k
= kilo =10
3
m
= mini =
10-
3
M
= mega = 10
6
µ
= micro = 10
-6
met.
= metal
mf r
= manufacturer
mod.
= modular or
modified
mtg
= mounting
n
= nano =10-
9
NC
= normally closed
NO
= normally open
NP
= nickel-plated
W
= ohm
obd
= order by
description
OD
= outside
diameter
p
= pico =10-
12
P.C.
= printed circuit
pot. = potentiometer
P-P
= peak-to-peak
ppm
= parts per
million
pvr
= peak reverse
voltage
rect = rectifier
rms
= root mean
square
S1
= silicon
SPDT = single pole,
double throw
SPST = single pole,
single throw
SS
= small signal
T
= slow-blow
tan.
= tantulum
T1
= titanium
V
= volt
var
= variabIe
ww
= wirewound
w = Watt
6-1
