HP 6268B User Manual

REF.
MFR. HP
DESIG.
DESCRIPTION
TQ MFR. PART NO.
CODE
PART NO.
RS
R41
fxd, comp 510 Ω ±5% ½W
2
EB-5115 01121 0686-5115 1
R42 fxd, met. film 560 Ω ±1% ¼W
1
Type CEB T-O
07716
0698-5146 1
R43
fxd, ww 50 Ω ±5% 5W
2
243E5005 56289
0811-1854 1
R44
fxd, met. oxide 22 Ω ±5% 2W 1 Type C42S
16299
0698-3609 1
R45
fxd, comp 820 Ω ±5% ½W
1
EB-8215
01121
0686-8215 1
R46 fxd, comp 1K Ω ±5% ½W
2 EB-1025
01121 0686-1025 1
R47 var. ww 5k Ω ±10%, Equalizer Adj.
2 Type 110-F4
11236 2100-1824 1
R48
fxd, comp 5.1k Ω ±5% ½W
1
EB-5125
01121 0686-5125
1
R49
fxd, comp 47 Ω ±5% ½W
1
EB-4705
01121 0686-4705 1
R50 fxd, comp 39 Ω ±5% ½W
1
EB-3905
01121 0686-3905
1
R51 fxd, comp 1k Ω ±5% ½W
EB-1025
01121
0686-1025
R52 fxd, met. film 61.9k Ω ±1% 1/8W
1 Type CEA T-O
07716
0757-0460 1
R53 fxd, comp 560 Ω ±5% ½W
1 EB-5615
01121 0686-5615 1
R54 fxd, ww 50 Ω ±5% 5W
243 E5005
56289
0811-1854
R56
fxd, comp 75 Ω ±5% ½W 1 EB-7505
01121 0686-7505 1
R57 fxd, ww 3.9 Ω 2W
1
Type BWH
07716 0811-1673 1
R58
fxd, ww 400 Ω ±5% 10W 1 Type 10XM
63743 0811-0942 1
R60 fxd, met. film 600 Ω ±1% 1/8W 1 Type CEA T-O
07716 0757-1100
1
R61
fxd, met. film 7.5K Ω ±1% 1/8W
Type CEA T-O
07716
0757-0440
R62
fxd, met. oxide 180 Ω ±5% 2W 1 Type C42S 16299 0698-3626 1
R63 fxd, met. film 499 Ω ±1% ¼W 1 Type CEB T-O
07716 0698-3207 1
R64 fxd, met. film 2k Ω ±1% ¼W 1 Type CEB T-O
07716 0757-0739 1
R65 fxd, comp I00kW ±5% ½W 2
EB-1045 01121 0686-1045 1
R66
fxd, comp 200k Ω ±5% ½W 3 EB-2045 01121
0686-2045
1
R67 fxd, comp 33k Ω ±5% ½W 1 EB-3335 01121 0686-3335 1
R68 fxd, met. film 5.49k Ω ±1% 1/8W Type CEA T-O
07716 0698-3382
R69 fxd, met. film 7.5k Ω ±1% 1/8W Type CEA T-O
07716 0757-0440
R69B fxd, met. film 3.4k Ω ±1% 1/8W
1
Type CEA T-O
07716 0698-4440 1
R70 var, ww 5k
Ω ±10%, Ramp Adjust.
Type 110-F4
11236 2100-1824
R71 fxd, met. film 12k Ω ±1% 1/8W 1
Type CEA T-O
07716 0698-5088 1
R72 fxd, met. film 45k Ω ±1% 1/8W 1
Type CEA T-O
07716 0698-5091 1
R73 fxd, comp 12k Ω ±5% ½W
1 EB-1235
01121
0686-1235
1
R74 fxd, comp 82k Ω ±5% ½W
1 EB-8235
01121 0686-8235 1
R75, 76 fxd, met. film 4,75k Ω ±1% 1/8W
2 Type CEA T-O
07716
0757-0437 1
R77
fxd, comp 430k Ω ±5% ½W 1
EB-4345 01121 0686-4345 1
R78 fxd, met. film 249k Ω ±1% 1/8W
1 Type CEA T-O
07716 0757-0270 1
R79
fxd, comp 3.9k Ω ±5% ½W
2
EB-3925
01121 0686-3925 1
R80 fxd, met. film 4.32k Ω ±1% 1/8W
1 Type CEA T-O
07716 0757-0436 1
R81 fxd, comp 4.7 Ω ±5% ½W
2
EB-47G5
01121 0698-0001
1
R82 fxd, comp 9.1k Ω ±5% ½W
2
EB-9125 01121
0686-9125 1
R83 fxd, comp 27 Ω ±5% ½W
1 EB-2705
01121 0686-2705
1
R84 fxd, comp 100k Ω ±5% ½W
EB-1045
01121 0686-1045
R85
fxd, comp 9.1k Ω ±5% ½W
EB-9125
01121 0686-9125
R86 fxd, met. oxide 270 Ω ±5% 2W
1
Type C42S
16299
0698-3629 1
R87 fxd, met. oxide 1.5k Ω ±5% 2W
1
Type C42S
16299
0698-3338 1
R88 fxd, comp 10 Ω ±5% ½W
2 EB-1OO5
01121 0686-1005 1
R90 fxd, met. oxide 820 Ω ±5% 2W
1
Type C42S 16299
0698-3637 1
R91 fxd, comp 180 Ω ±5% 1W
1
GB-1815
01121
0689-1815 1
R92 fxd, ww 220 Ω 2W
1
Type BWH
07716 0811-1763 1
R93 fxd, comp 3.9k Ω ±5% ½W
EB-3925 01121 0686-3925
R94 fxd, comp 510 Ω ±5% ½W
EB-5115
01121
0686-5115
R95 fxd, met. film 1.5k Ω ±1% 1/8W
2
Type CEA T-O
07716 0757-0427 1
R96 fxd, comp 200k Ω ±5% ½W
EB-2045
01121 0686-2045
R97
fxd, comp 4.7 Ω ±5% ½W
EB-47G5
01121 0698-0001
R98
fxd, comp 10 Ω ±5% ½W
EB-1005
01121 0686-1005
R99 fxd, comp 200k Ω ±5% ½W
EB-2045
01121 0686-2045
R101
var. ww 250 Ω ±10%, Ammeter Adj.
2 Type 110-F4
11236 2100-0439 1
R102
fxd, met. film 909 Ω ±1% 1/8W
1 Type CEA T-O
07716
0757-0422 1
6269B
6-6
TM11-6625-2958-14&P
