HP 6268B User Manual

REF.
MFR. HP
DESIG.
DESCRIPTION
TQ MFR. PART NO.
CODE
PART NO.
RS
TS101 Thermal Switch, open 230°F, close
200°F
1 28480 0440-0079 1
A5 FRONT PANEL ASSEMBLY
A5 Front Panel Assembly
1
28480 06269-60005
CB1 Circuit Breaker, 25A @ 250Vac max. 1
AM33 Curve 5
74193
2110-0213 1
DS1
Indicator Light, Neon, Red
1
599-124
72765 1450-0048 1
DS2 Overvoltage Indicator, 6V, Amber
1 MCL-A3-1730
07137 1450-0305 1
Ml
Voltmeter, 0-50V
1
28480
1120-1173 1
M2
Ammeter, 0-60A 1
28480 1120-1181 1
R121 var. ww 10k Ω ±5%, Voltage
Control, Coarse
2
28480 2100-1854 1
R122 var. ww 50 Ω ±5%, Voltage
Control, Fine 2
28480 2100-1858 1
R123
var. ww 200 Ω ±5%, Current
Control, Coarse
1
28480
2100-1856 1
R124
var.
ww 10
Ω ±5%, Current
Control, Fine 1
28480 2100-1857 1
R125
var. ww 10k Ω ±5%, Overvoltage
Adjustment
28480
2100-1854
CHASSIS - ELECTRICAL
B2 Fan
1 8500
23936
3160-0056 1
C19
fxd, elect. 15µF 50Vdc
1
150D156X0050R2
56289
0180-1834 1
C101-C104 fxd, elect. 50,000µF 50Vdc 4
28480
0180-2346 1
C110, 111
fxd, ceramic .01µF 300Vdc
2
41C21A5
56289
0160-2568 1
T1
Power Transformer
1
28480 06269-80091 1
CHASSIS ASSEMBLY- MECHANICAL
Chassis Assembly (Welded) 1
28480 5060-6186
Bracket, RFI Filter Mounting 2
28480 5000-6257
Standoff, Insulated, RFI Filter
Mounting 4
28480 0380-0902
Grommet, 5/8” (Internal
Chassis Divider) 1
1661 73734 0400-0062
Cover 2
28480 5000-6250
Chassis, Internal, Ckt. Board Tray 1
28480 5000-6248
Chassis, Internal, Capacitor Tray 1
28480 06269-00002
Bus Bar, C101-C102
2
28480 5000-6251
Bus Bar, C103-C104
2
28480 5000-6253
Clamp, C101-C104 3
28480 5000-6017
Bracket, Fan B2
2
28480 06269-00003
Rear Panel (Blank, with labeling) 1
28480 06260-60008
Cover, AC Input Barrier Block 1
28480
5000-6249
Cover, Rear Control Barrier Strip
1
28480 00712-20001
Bus Bar, Output
2
28480
5000-6252
Barrier Block, AC Input
1 603-3
75382 0360-1596 1
Rubber Bumper 4 2097-W 87585 0403-0089
Spacer, Insulated, AC Input
Barrier (2), Output Bus Bars (4)
6
28480 0380-0710 6
Serial I.D. Plate 1
28480
7120-1111
6269B
6-8
TM 11-6625-2958-14&P
