Model
6960
A
Caution:
Attention:
d)
Ripple.
Section
V
At first
select
the
36
V-0.3
A
range
and
adjust
short
circuit
current
by
changing
the
position
of
R 7 to
340
mAo
Then
switch
the
power
supply
into
the
18V-0.6
A
range
and
adiust
short
circuit
current
with
R
10
to
680
mA.
Do
not
allow
current
ratings
of
more
than
400
mA
to flow
through
either
of
the
series
regulators.
This may
destroy
the
series
regulators
Q 1
and
Q 2 !
Before performing this odiust,
the
instrument has
to
be
warmed
up to its normal
operotir\8
tenlpeia~ure.
Measure
ripple
according
to
paragraph
5-8
C.
Change
th"
line
voltage
of
the
power supply
between
198
V
and
242
V.
Within
the
whale
runge
the
ripple
vol-
tage
should not
exceed
150
/u
Veff.
If
'here
is
a
grad
..
,.:,;
;:~'J;'
i",ple
over
I
150
/,Vrms
while
decreasing
the
line
voltage
towards
198
V,
transistor
Q 6
has
stopped
working.
Remove R 33
and
replace
it with a
aecade
resistance.
Vary
the
input
line
voltage
between
198 V
and
242
V
and
adiust
the
decade
so
that
in
the
whole
range
the
ripple
voltage
remains
below
150
/,Vrms.
At
the
some time
check
the
voltage
between
minus
lead
of
capacitor
Cl
and
-S.
It
<.hould
read
-14V
:: 2
%,
otherwise
transistor
Q 4 will
not
regulate
properly.
Replace
the
decade
value
with a
fixed
resistor
of
equal
value.
e)
Load
Regulation.
For measuring
circuit
refer
to
paragraph
5-8
d.
If
the
output
voltage
change
is
greater
than
5
mV
while
switching
the
load
off
and
on,
adjust
resistor
R
23
so
that
the
change
is
within
the
specification.
After
setting
R 23 turn
the
VOL-
TAGE ADJUST
knob
fully
counterclockwise.
A
de
voltmeter
across
the
output
terminals
of
the
power
supply
must
indicate
a
negative
voltage
between
-2
mV
and
-100
mY.
f)
Line
Regulation.
If
the
adjustment
described
in
paragraph
5-10
d has
been
done
carefully
the
output
voltage
change
caused
by
input
line
voltage
changes
should
normally
be
within
the
specification.
If
there
are,
nevertheless,
excessive
changes,
remove R 37
and
replace
it
with
a
decade
resistance.
The
decade
is
adjusted
so
the
change
of
output
voltage
lies
within
specification.
Replace
the
decade
with
a
fixed
resistor
of
equal
value.
5-7
