HP 8447D - Page 47

DRAFT 45
Operation and Service Manual
Parts and Service
U2 08447-60044 5086-7767 replacement kit (for use with
08447-60045 assy).
28480 08447-60044
W1 8120-1348 5 1 Cable assy: power, detachable 70903 KHS-7041
W2 08447-20002 5 1 Cable assy: Type-N INPUT
(Opt 010 and 011 only)
28480 08447-20002
W2 08447-20006 9 1 Cable assy: BNC INPUT 28480 08447-20006
W3 08447-20003 6 1 Cable assy: Type-N OUTPUT
(Opt 010 and 011 only)
28480 08447-20003
W3 08447-20007 0 1 Cable assy: BNC OUTPUT 28480 08447-20007
W4 08447-20004 7 1 Cable assy: Type-N INPUT (Opt 010) 28480 08447-20004
W4 08447-20008 1 1 Cable assy: BNC INPUT 28480 08447-20008
W5 08447-20005 8 1 Cable assy: Type-N OUTPUT (Opt 010) 28480 08447-20005
W5 08447-20009 2 1 Cable assy: BNC OUTPUT 28480 08447-20009
W6
08447-20014
9 1 Cable assy: jumper (Opt 011 only) 28480 08447-20014
XF1 Fuseholder (includes the following parts)
XF1MP1 2110-0564 8 1
Fuseholder body 12A max for UL
28480 2110-0564
XF1MP2 2110-0565 9 1 Fuseholder cap 12A max for UL 28480 2110-0565
XF1MP3 2110-0569 3 1 Nut-fuseholder thread 28480 2110-0569
XQ1 0340-0664 1 Insulator: xstr mounting (TO-3) 28480 0340-0664
XF1MP4 1400-0090 9 1 Washer: lock sst for 1/2 thread 28480 1400-0090
0360-0368 7 1 Termination: solder stud 78189 2168-12-01
0900-0016 8 1 O-ring 0.688” OD 00000 OBD
Table 10 HP 8447F Replaceable Parts
Ref
Des
HP Part
Number
CD qty Description
Mfr
Code
Mfr Part
Number
