DRAFT 5
Operation and Service Manual
General Information
a. Variation over any 50 MHz band from 0.1-1300 MHz is typically <0.15 ns.
b. Variation over any 50 MHz band from 0.1-1300 MHz is typically <0.25 ns.
Harmonic distortion
−30 dB for 0 dBm output (typi-
cal)
−30 dB for +8 dBm output
Typical output for <−60 dB harmonic distortion −30 dBm −20 dBm
VSWR, 1 to 1300 MHz
<2.0:1 Input
<2.2:1 Output
−−
VSWR, 1 to 1400 MHz
−− <2.2:1 Input
<2.5:1 Output
Impedance 50 Ω 50 Ω
Reverse isolation
>40 dB >40 dB
Maximum DC input voltage ±10 V ±10 V
Typical risetime 400 ps 420 ps
Typical group delay
1.1 ns
a
1.5 ns
b
Net weight 3 lbs 8 oz (1.59 kg) 3 lbs 8 oz (1.59 kg)
Option 001 3 lbs 14 oz (1.75 kg)
−−
Option 010 3 lbs 1 oz (1.84 kg) 3 lbs 10 oz (1.64 kg)
Option 011 4 lbs 10 oz (1.64 kg)
−−
Dimensions 8 1/2 in (216 mm) by 5-1/2 in (130 mm) by 3-3/8 in (85.8 mm)
Power Requirements 115 or 230 Vac ±10%, 48 to 440 Hz, 15 Watts, 27 VAmax
Environmental
Operation: 0
°C to +55°C
Storage:
−40°C to +75°C
Table 1 HP 8447D and HP 8447E Specifications
Specifications
HP 8447D
Preamp
HP 8447E
Power Amp
