4. Remove the battery (see Battery on page 44).
5. Remove the keyboard (see
Keyboard on page 60).
Remove the switch cover:
1. Turn the computer upside-down, with the rear toward you.
2. Remove the three Phillips PM2.0×2.0 broadhead screws that secure the switch cover to the
computer.
3. Turn the computer right-side up, with the front toward you.
4. Open the computer as far as possible.
5. Release the switch cover by lifting the left and right inside edges of the switch cover (1) until it
disengages from the computer.
6. Lift the switch cover (2) up and forward and rest it on the computer while being careful not to
disconnect the LED board cable from the system board.
66 Chapter 4 Removal and replacement procedures
