4. Lift the upper left corner of the keyboard (1) and swing the left side of the keyboard (2) forward.
5. Turn the computer right-side up, with the front toward you.
6. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and
disconnect the keyboard cable (2) from the system board.
7. Release the ZIF connector (3) to which the pointing stick cable is attached, and disconnect the
pointing stick cable (4) from the system board.
8. Remove the keyboard.
Reverse this procedure to install the keyboard.
62 Chapter 4 Removal and replacement procedures
