Page #15 background imageLoading...
Page #15 background image
HP 9512 Switch Chassis
(JC125B)
Included accessories
2 HP 9512/9505/8812/8805 Spare Fan Assembly (JC109A)
Ports
2 switch fabric slots
12 I/O module slots
Supports a maximum of 192 10-GbE ports or 576 autosensing 10/100/1000 ports or 576 SFP ports, with
optional module
Power supplies
2 power supply slots
1 minimum power supply required (ordered separately)
Fan tray
includes: 2 x JC109A
2 fan tray slots
Physical characteristics
Dimensions
17.4(w) x 17.72(d) x 29.65(h) in (44.2 x 45.0 x 75.3 cm) (17U height)
Weight
132.28 lb. (60 kg), Fully loaded chassis, two fabrics, two power supplies, and a
full complement of typical I/O modules
Full configuration weight
242.5 lb. (110 kg)
Memory and processor
Fabric
PowerPC @ 1000 MHz, 128 MB flash, 1 GB RAM, 256 MB compact flash
I/O Module
PowerPC @ 667 MHz, 512 MB RAM
Mounting
Mounts in an EIA standard 19-in. rack or other equipment cabinet (hardware included); horizontal surface
mounting only
Performance
1000 Mb Latency
< 6.0 µs (FIFO 64-byte packets)
10 Gbps Latency
< 6.0 µs (FIFO 64-byte packets)
Throughput
857 million pps
Routing/Switching
capacity
1440 Gbps
Routing table size
256000 entries
Reliability
Availability
99.999%
Environment
Operating temperature
32°F to 113°F (0°C to 45°C)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Electrical characteristics
Voltage
100-120/200-240 VAC
DC Voltage
-48 V/-60 V
Current
16/92 A
Power output
3500 W
Frequency
50/60 Hz
Notes
Based on a 3500 W DC power supply
Safety
UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11
QuickSpecs
HP 9500 Switch Series
Technical Specifications
DA - 13773 North America — Version 10 — July 12, 2013
Page 15
