HP 9500 Series

HP 9505 Switch Chassis (JC124B)
Included accessories 1 HP 9512/9505/8812/8805 Spare Fan Assembly (JC109A)
Ports 2 switch fabric slots
5 I/O module slots
Supports a maximum of 80 10-GbE ports or 240 autosensing 10/100/1000 ports or 240 SFP ports, with
optional module
Power supplies 2 power supply slots
1 minimum power supply required (ordered separately)
Fan tray includes: 1 x JC109A
1 fan tray slot
Physical characteristics Dimensions 17.4(w) x 17.72(d) x 19.13(h) in (44.2 x 45.0 x 48.6 cm) (11U height)
Weight 88.18 lb. (40 kg), Fully loaded chassis, two fabrics, two power supplies, and a
full complement of typical I/O modules
Full configuration weight 154.32 lb. (70 kg)
Memory and processor Fabric PowerPC @ 1000 MHz, 128 MB flash, 1 GB RAM, 256 MB compact flash
I/O Module PowerPC @ 667 MHz, 512 MB RAM
Mounting Mounts in an EIA standard 19-in. rack or other equipment cabinet (hardware included); horizontal surface
mounting only
Performance 1000 Mb Latency < 6.0 µs (FIFO 64-byte packets)
10 Gbps Latency < 6.0 µs (FIFO 64-byte packets)
Throughput 357 million pps
Routing/Switching
capacity
600 Gbps
Routing table size 256000 entries
Reliability Availability 99.999%
Environment Operating temperature 32°F to 113°F (0°C to 45°C)
Operating relative
humidity
5% to 95%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Electrical characteristics Voltage 100-120/200-240 VAC
DC Voltage -48 V/-60 V
Current 16/92 A
Power output 3500 W
Frequency 50/60 Hz
Notes Based on a 3500 W DC power supply
Safety UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11
QuickSpecs
HP 9500 Switch Series
Technical Specifications
DA - 13773 North America — Version 10 — July 12, 2013 Page 19
