HP 9500 Series User Manual

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP 9505 Switch Chassis JC124B
5 - I/O module slots
Must select min 1 Power Supply
HP 9508-V Switch Chassis JC474B
8 - I/O module slots
Must select min 1 Power Supply
HP 9512 Switch Chassis JC125B
12 - I/O module slots
Must select min 1 Power Supply
Modules
Ethernet Modules
(JC124B Switch Only ) System (std 0 // max 5) User Selection (min 0 // max 5) per enclosure
(JC474B Switch Only ) System (std 0 // max 8) User Selection (min 0 // max 8) per enclosure
(JC125B Switch Only ) System (std 0 // max 12) User Selection (min 0 // max 12) per enclosure
HP 9500 16-port 10GbE SFP+ Module JC108A
min=0 \ max=16 SFP + Transceivers See Configuration
Note:2
HP 9500 4-port 10GbE XFP Module JC114A
min=0 \ max=4 XFP Transceivers See Configuration
Note:3
HP 9500 2-port 10GbE XFP Module JC112A
min=0 \ max=2 XFP Transceivers See Configuration
Note:3
HP 9500 48-port GbE SFP Module JC113A
min=0 \ max=48 SFP Transceivers See Configuration
Note:1
HP 9500 24-port GbE SFP Module JC123A
min=0 \ max=24 SFP Transceivers See Configuration
Note:1
QuickSpecs
HP 9500 Switch Series
Configuration
DA - 13773 North America — Version 10 — July 12, 2013 Page 8
