Table 2-9 Internal assemblies
Ref Description Part number Qty
1 Roller, paper pick-up RL1-2671-000CN 1
2 Intermediate transfer belt assembly (ITB) RM2-0175-000CN 1
3 Fuser delivery assembly (110-127 V) RM2-0157-000CN 1
3 Fuser delivery assembly (220–240 V) RM2-0167-000CN 1
4 Base plate assembly RM2-0160-000CN 1
5 Separation pad assembly RM2-0170-000CN 1
6 Main tray assembly RM2-0144-000CN 1
7 Inner cover assembly RM2-0139-000CN 1
8 Support, frame RC3-0230-000CN 1
9 Cover, grounding cable RC3-5365-000CN 1
10 Low voltage power supply assembly (110-127V) RM2-7292-000CN 1
10 Low voltage power supply assembly (220-240V) RM2-7293-000CN 1
11 Engine controller PCA RM2-7300-000CN 1
Fax module–Asia/US (M177 model) (not shown) CF206-60001 1
Fax module–EU (M177 model) (not shown) CF207-60001 1
Fax module–Brazil (M177 model) (not shown) CF208-60001 1
PCA, formatter (M176 model) (not shown) CF547-60001 1
PCA, formatter (M177 model) (not shown) CZ165-60001 1
WiFi board (M177 model) (not shown) 1150-7957 1
ENWW Internal assemblies 111
