Table 2-11 Scanner assemblies (M176 model)
Ref Description Part number Qty
3 SSA FFC Cable, 20 Pin CZ165-60106 1
4 Scan bezel assembly CF547-60112 1
6 Scan drive system assembly CZ181-60104 1
7 Scanner base assembly CF547-60102 1
CAUTION: Replace the internal scanner assemblies only in a dust-free environment.
ENWW Scanner and document feeder (ADF) assemblies 115
