Table 2-8 Covers, panels, and doors
Ref Description Part number Qty
1 Cover, fuser RC3-5345-000CN 1
2 Cover, right RC3-5348-000CN 1
3 Door, cartridge RC3-5357-000CN 1
4 Left cover assembly RL1-3930-000CN 1
5 Right upper cover assembly RL1-3936-000CN 1
6 Upper cover assembly RM2-0138-000CN 1
7 Operation panel assembly RM2-0142-000CN 1
8 Rear cover/secondary transfer assembly RM2-0162-000CN 1
9 Power supply cover assembly RM2-0164-000CN 1
10 Extension tray assembly RM2-0168-000CN 1
11 Cover, flat cable RC3-5353-000CN 1
12 Cover, dust RC3-5146-000CN 1
Control panel assembly–2 line LCD (M176 model) (not shown) CF547-60109 1
Control panel assembly–touchscreen (M177 model) (not shown) CF547-60110 1
Fax rubber cap (M177 model) (not shown) CZ185-40001 1
ENWW Covers, panels, and doors 109
