HP Compaq 2230s Specification

Display Internal 12.1-inch diagonal WXGA anti-glare (1280 x 800 resolution)
12.1-inch diagonal WXGA BrightView (1280 x 800 resolution)
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
HDMI 1.3 port supports direct connection to high-definition displays with
up to 1920 x 1080 resolution and 7-channel audio with one convenient
cable (not included)
NOTE: Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
Memory Standard 800 MHz DDR2 SDRAM; two slots supporting dual channel memory
1024 MB or 2048 MB
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system
will perform at the lower memory speed. Full availability of 4 GB or more of memory requires
Windows Vista Business 64-bit or Linux. With Windows 32-bit operating systems, the amount of
usable memory is dependent upon your configuration, so that above 3 GB all memory may not be
available due to system resource requirements.
Communications Marvell Ethernet (10/100/1000 NIC) *
56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab
for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed
transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem
availability is subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN options featuring support for the
latest industry standards. Integrated Bluetooth is also available (factory configurable only) and can
be combined with any of the supported wireless LAN options.
All 802.11 integrated
wireless LAN options
Wi-Fi certified *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-
GTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
Intel WiFi Link 5100 Integrated support for 802.11a, b, g, and n draft 2.0 *
Up to 300 mbps data rate
Intel WiFi Link 5100 Integrated support for 802.11 a, b and g
Up to 54 mbps data rate
Broadcom 4322AGN
802.11a/b/g/draft-n Wi-
Fi Adapter
Integrated support for 802.11a, b, g, and n draft 2.0 *
Up to 300 mbps data rate
Broadcom 4312G
802.11b/g
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54 mbps data rate
QuickSpecs
HP Compaq 2230s Notebook PC
Standard Features
DA - 13106 Worldwide QuickSpecs — Version 7 — 1/8/2009 Page 4

HP Compaq 2230s Specifications

General

Processor model	-
Processor family	Intel® Celeron® M
Processor manufacturer	Intel
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	No
Total storage capacity	120 GB
Display surface	Gloss
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	4 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Type	PC
Modem speed	56 Kbit/s
Internal modem	Yes
Wireless technology	802.11a/b/g/n draft 2.0
Bluetooth version	2.0+EDR
Networking features	Marvell Ethernet (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	4
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
AC adapter power	65 W
Battery performance	37 W
Pointing device	Touchpad + Scroll zone
Country of origin	China

Weight and Dimensions

Depth	294 mm
Height	226 mm
Weight	1850 g
Height (front)	28 mm
